搭一套日志收集系统

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12

# 下载脚本
wget https://artifacts.elastic.co/downloads/elasticsearch/elasticsearch-5.3.0.zip
sha1sum elasticsearch-5.3.0.zip
unzip elasticsearch-5.3.0.zip
cd elasticsearch-5.3.0/

# 运行脚本，默认配置
bin/elasticsearch

# 启动成功可以查看相关参数
http://localhost:9200/_nodes
http://localhost:9200/_cat/indices?v&pretty

1
2

# 默认配置启动
logstash -e 'input { stdin { } } output { stdout {} }'

1
2

# 默认配置启动
nohup ./kibana >> ../logs/kibana.log &

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24

# 创建 Kafka 主题
kafka-topics.sh --zookeeper localhost:2181 --create --topic kafka-elk-log --partition 1 --replication-factor 1

# Logstash 配置文件，保存至 etc/ 目录下
 input {
     stdin { }
 }
 output {
     kafka {
         topic_id => "kafka-elk-log"
         bootstrap_servers => "localhost:9092"
         batch_size => 5
         codec => "plain"
     }
     stdout {
         codec => rubydebug
     }
 }

# 创建配置文件，运行 Logstash
logstash -f ./etc/logstash_input_kafka

# 查看是否写入 Kafka，因为只有一个分区，所以容易查看数据
kafka-run-class.sh kafka.tools.DumpLogSegments --files /tmp/kafka-logs/kafka-elk-log-0/00000000000000000000.log --print-data-log

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22

# Logstash 配置文件
 input {
     kafka {
         codec => "plain"
         group_id => "kafka_elk_group"
         client_id => logstash
         topics => "kafka-elk-log"
         bootstrap_servers => "localhost:9092"
         auto_offset_reset => "earliest"
         consumer_threads => 5
     }
 }
 output {
     elasticsearch {
         hosts => ["localhost:9200"]
         codec => "plain"
         index => "kafka_elk_log-%{+YYYY.MM.DD}"
     }
 }

# 启动 Logs
logstash -f ./etc/logstash_input_kafka

1

kafka-topics.sh --zookeeper localhost:2181 --create --topic acount-access-log --partitions 3 --replication-factor 1
